The structure of the furnace (car bottom furnace)

The press furnace temperature distribution in the furnace along the longitudinal direction is divided into a preheating section, a heating section and a soaking zone; feed end of the furnace temperature lower preheating section, its role is to use the heat of the furnace gas, in order to improve the thermal efficiency of the furnace.
Heating as the main heating segment, the gas temperature is higher, in order to facilitate the rapid heating. Soaking zone is located in the discharge end, the gas temperature and metal material temperature difference is small, to ensure uniform temperature of the charge blank section. Stove for heating small cut fabric blank only warm-up and the heating section. Customary to also install the burner in the furnace for tropical divided furnace segment, in accordance for the number of tropical stove called the one-, two-stage, to five sections, Six-. 50 to 60 years, the mill capacity to increase the length of the pusher-type furnace is limited by the length of the Pusher not be too long, so start at the feed end of the increase for tropical canceled heating preheating section, in order to improve The productivity of the unit hearth area.
Since the 1970s, due to energy needs, but also emerging stepping furnace allows to increase the length of the furnace, and additional heating preheating section, the best hearth yield per unit area of 600 to 650 kg / (m 2 · Time), the heat consumption of approximately (0.3 to 0.5) × 106 kcal / ton.
The continuous heating furnace usually use the fuel gas, heavy oil, or pulverized coal, some lump coal burning. In order to effectively utilize the exhaust heat, preheated air and installed in the flue gas heat exchanger, or install a waste heat boiler.

High Temperature Bogie-forging furnace

High Temperature Bogie-forging furnace with high temperature resistant fibers and light and energy saving high-quality energy-saving lining refractory bricks, heating elements for high temperature resistance alloy strip or wire or silicon carbide material, reliable and durable. Trolley furnace sealed, the the double sand seal structure. The gap between the body back wall and the furnace refractory fiber blanket fixed on the furnace. Let trolley rear end surface of refractory fiber blanket contact.
High Temperature Bogie-forging furnace temperature control system:
Trolley impact-proof bricks, self-sealing trolley and door, integration with rail, foundation installation is not on level ground can be used. High Temperature Bogie-forging furnace using computer control cabinet temperature, automatically heat up in accordance with the process requirements, insulation, power outages and other functions. Recording instruments have recorded over-temperature alarm, burnout alarm and other functions.
High Temperature Bogie-forging furnace features:
High Temperature Bogie-forging furnace microcomputer temperature control system according to customer needs, configure the high-middle and low domestic, joint venture, or imported temperature controller, or paperless recorder and on-line communication port, the PC distribution control.
High Temperature Bogie-forging furnace heating mode selectable resistance or gas, fuel oil heating.
The lining structure can also choose the fiber structure or composite structure.
According to user requirements design and manufacture of non-standard products, power from 30-800kw.
High Temperature Bogie-forging furnace trolley:
High Temperature Bogie-forging furnace trolley welded steel and steel Charpy structural design, consider the the trolley dead weight and load-bearing quality, together after deformation, to stay on the body of the trolley expansion joints and triangular ribs, to ensure that no deformation in the hot state.

Sealed box furnace

Sealed box furnace description:
Sealed box is used for professional heat treatment furnaces industrial furnaces, heat treatment effect. Sealed box furnace are mainly the following
Positive stove sealed box:
Sealed box is a dual chamber structure furnace, muffle heating chamber is no structure, using advanced refractory brick, door cylinder individually designed using advanced compression seal structure, good sealing, no leakage atmosphere. Box is using electric heating furnace, radiant tube evenly distributed on both sides and at the bottom of the furnace, heat-resistant steel roof with a stirring fan to ensure temperature uniformity. Fengdong Box normalizing furnace heating process pass into the protective atmosphere, the workpiece without oxidation. Sealed box is out of the stove automatic and manual feeding mode (optional), box-type furnace cooling chamber is equipped with a large flow variable speed cooling fan, cooling speed.
Sealed box annealing furnace:
Sealed box annealing furnace for the single-chamber structure, the heating chamber with advanced refractory brick, sealed box annealing furnace door are individually designed cylinder compression seal structure, good sealing, no leakage atmosphere. Box is using electric heating furnace, radiant tube evenly distributed on both sides and at the bottom of the furnace, heat-resistant steel roof with a stirring fan to ensure temperature uniformity. Fengdong box annealing furnace heating process pass into the protective atmosphere, the workpiece without oxidation.

Laboratory chamber furnace

Laboratory chamber furnace:
The lab box furnace in THERMCONCEPT in a variety of sizes, from 5 to rise to 45 liters (technical data see page 6), the internal specifications and maximum operating temperature of the furnace can be modified according to the needs of the laboratory. Available working voltage of 230V models. The movable bottom of the laboratory box furnace can also add the movable bottom plate can be easily replaced from the outside of the furnace. All maximum temperature of 1100 ° C / 1200 ° C / 1300 ° C in the box-type furnace can be used to move the base plate. Built-in air circulation laboratory chamber furnace with optional fan for internal air circulation, the air circulation system can improve the heat transfer of the heating element, which will help control the temperature and uniformity. This device is suitable for a maximum temperature of 1100 ° C the box-type furnace.
Laboratory box furnace parts:
By matching all kinds of accessories, we can according to your needs and functions best with a box furnace:
Exhaust chimney (with exhaust fan and with no exhaust fan).
2 exhaust stack, with exhaust fan and catalytic converters.
3 over-temperature protection regulator, according to the EN 60519-2 standard for thermal protection class 2 adjust the temperature.
4 mounted at the rear of the furnace protective gas connecting port.

To protect the atmosphere box furnace

Protective atmosphere box furnace uses:
Protect the atmosphere box furnace use a very wide range, suitable for industrial and mining enterprises, scientific research institutes, universities laboratory. For chemical analysis, physical measurement, and metal parts and small mold steel heat treatment under protective atmosphere.
Protective atmosphere box furnace features:
1, this series of protective atmosphere box furnace of high quality steel Seiko made, electrostatic spraying the surface appearance.
2 studio quality refractory firing from the furnace, the heating element can be configured depending on the temperature (usually high temperature resistance wire, silicon carbide, molybdenum wire, silicon molybdenum rod).
3, insulation materials made of high quality aluminum silicate refractory fiber cotton.
4, the gas system with a flow meter, valve, the overall furnace shell sealed globe valves, equipment, the furnace mouth sealed with silicone rubber plus water-cooled.
Supporting electric furnace temperature control part of the adjustable PID intelligent instrument control may be prepared more than one block, precise control of the firing process, and with the flow, limiting, thermal protection function.
6, when the door is open automatic power-off function to ensure maximum safety of users. The equipment is heating up fast, good insulation properties, temperature uniformity, the use of safe, convenient, energy saving, environmental protection and other features.

Crucible furnace

Introduction of crucible furnace:
For laboratory, industrial and mining enterprises, scientific research units for elemental analysis determination of melting metal and small pieces of steel heat treatment heating.
The crucible furnace shell are cylinder. Furnace shell of welded Pu steel. Studio one by refractory fired into the the overall furnace, furnace wear silk tank, the heating element placed on the wear silk tank. Between the furnace and the furnace shell with fan foam brick, vermiculite insulation. The electric furnace with temperature control, furnace temperature can be measured with thermocouples.
Crucible furnace Features:
1, using intelligent instrument temperature control, high precision temperature control.
2, the furnace wire wound around the furnace liner is reasonably arranged, temperature uniformity.
3, can be customized according to customer needs non-standard models.
Crucible furnace applications:
Crucible furnace is used for various industrial and mining enterprises, universities, research institutes for elemental analysis, small pieces of steel hardening, annealing, tempering heating. The carbon heater dedicated to steel mills, iron foundries, laboratories for carbon and sulfur analysis. All high-temperature furnace with temperature controller, with the thermocouple temperature indicating controller, automatic control of temperature in the furnace. Analog and digital temperature control instrument is divided into two kinds. The other can be customized all kinds of special specifications large box-type furnace, tube furnace, tempering furnace pit.

Box-type resistance furnace

Box-type resistance furnace Adaptation
Suitable for ceramics, rare earth magnetic materials, wear-resistant materials such as high-temperature continuous firing.
Box-type resistance furnace Features
1, the series resistance furnace shell made of high quality cold-rolled steel plate, the surface coating process, the door side of the open structure, flexible opening and closing.
2, the temperature box enclosed fire, electric alloy wire heating element coiled into a spiral into the walls of the furnace, heat and temperature uniformity, extending the service life.
3, high-temperature tube resistance furnace with high temperature combustion tube, as in silicon carbide heating elements installed in the furnace jacket.
4, high temperature box resistance furnace with silicon carbide heating element directly in the furnace installation, high thermal efficiency.
5, the series resistance furnace insulation materials selection 0.4-0.6 lightweight foam insulation brick and aluminum silicate fiber cotton, so that the heat storage capacity and thermal conductivity decreased, resulting in the heat storage capacity of the furnace, heating time is shortened, low surface temperature, air furnace power losses, the power consumption is greatly reduced.

Low-temperature box furnace

Introduction to the low-temperature box furnace
Uses: mainly used steel workpiece quenching, normalizing, annealing conventional heat treatment with special equipment.
Features:
1. Electric furnace loading capacity, high productivity, especially for small and medium-sized mechanical heat treatment heating, energy saving up to 20%, temperature uniformity, the DRO automatically furnace temperature control, high precision;
2. Electric furnace installed Imperial material, operating conditions;
3. The seal of the door and the furnace for self-sealing, without manual sealing
4. The electric furnace has interlock protection device to prevent misoperation due to failures and accidents;

Box-type resistance furnace

Box-type resistance furnace Adaptation
Suitable for ceramics, rare earth magnetic materials, wear-resistant materials such as high-temperature continuous firing.
Box-type resistance furnace Features
1, the series resistance furnace shell made of high quality cold-rolled steel plate, the surface coating process, the door side of the open structure, flexible opening and closing.
2, the temperature box enclosed fire, electric alloy wire heating element coiled into a spiral into the walls of the furnace, heat and temperature uniformity, extending the service life.
3, high-temperature tube resistance furnace with high temperature combustion tube, as in silicon carbide heating elements installed in the furnace jacket.
4, high temperature box resistance furnace with silicon carbide heating element directly in the furnace installation, high thermal efficiency.
5, the series resistance furnace insulation materials selection 0.4-0.6 lightweight foam insulation brick and aluminum silicate fiber cotton, so that the heat storage capacity and thermal conductivity decreased, resulting in the heat storage capacity of the furnace, heating time is shortened, low surface temperature, air furnace power losses, the power consumption is greatly reduced.

Scope and features of the box-type resistance furnace

Box-type resistance furnace suitable for scientific research units, product quality inspection center, industrial and mining enterprises, laboratories for the performance of experimental products or materials under high temperature conditions. Furnace shell made of high quality welded steel folding, indicating that the electrostatic spraying process. The studio is made of refractory furnace. Digital temperature control.
Features:
1, the series resistance furnace shell made of high quality cold-rolled steel plate, the surface coating process, the door side of the open structure, flexible opening and closing.
2, the temperature box enclosed fire, electric alloy wire heating element coiled into a spiral into the walls of the furnace, heat and temperature uniformity, extending the service life.
3, high-temperature tube resistance furnace with high temperature combustion tube, as in silicon carbide heating elements installed in the furnace jacket.
4, high temperature box resistance furnace with silicon carbide heating element directly in the furnace installation, high thermal efficiency. 5, the series resistance furnace insulation materials selection 0.4-0.6 lightweight foam insulation brick and aluminum silicate fiber cotton, so that the heat storage capacity and thermal conductivity decreased, resulting in the heat storage capacity of the furnace, heating time is shortened, low surface temperature, air furnace power losses, the power consumption is greatly reduced.

High and low temperature of the high and low temperature approach to troubleshooting troubleshooting methods

High and low temperature in the high-temperature test, such as temperature change to reach the test temperature, you can check the electrical system, troubleshooting one by one. Such as temperature rose slowly, it is necessary to check the air circulation system, look at the damper is open normal air circulation, and vice versa, check the air circulation motor is functioning properly. If the temperature overshoot powerful then you need to set the parameters of the PID tuning. If the temperature rise directly, over temperature protection, then, the controller failed, control instruments to be replaced.
Second, the high and low temperature in the sudden failure of the test is running, the control on the instrument corresponding fault display prompts and voice alarm. The operator can control the operational use of the device in the Troubleshooting chapter quickly check which category failure, you can ask professionals to quickly troubleshoot to ensure the normal conduct of the trial. Other environmental testing equipment in use there will be other phenomena, it should be a specific phenomenon, specific analysis and troubleshooting. Environmental testing equipment but also regular maintenance, refrigeration system condenser cleaned regularly, lubrication, electrical control system maintenance checks on a regular basis for moving parts shall be specified, such work is essential
Third, the high and low temperature low temperature reach test indicators, then you have to observe the changes of the temperature, the temperature drop is slow, or the temperature to a certain value tends to increase in temperature, the former is necessary to check, and low temperature Before the test, whether the studio drying, the studio will remain dry and then test sample into the working chamber to do the test, the working chamber of the test sample is placed too much, so that indoor air can not be the full cycle of exclusion of the above reason, we must consider whether it is a fault in the cooling system, so that would be for the manufacturers of maintenance professionals. The latter phenomenon is the use environment of the device is bad due to the ambient temperature, the device is placed to meet the requirements placed distance from the wall (Case) (in the device operation instructions for use are specified).
Fourth, the high and low temperature in the hot and humid test, the actual humidity will reach 100% or the actual humidity and target humidity vary widely lot of low value, the former phenomenon: It may be caused by dry gauze on the wet bulb sensor, it is necessary to check whether the lack of water in the water tank of the wet bulb sensor, the water level in the tank is automatically controlled by a level controller, check the water level controller water supply system is normal water supply, water level controller is working properly. Another possibility is that the wet bulb gauze from the use of a long time, or the quality of water purity reasons, make the gauze hardens, the gauze can not absorb moisture and dry, replace or clean gauze to exclude the above phenomenon. The latter phenomenon is mainly humidification system does not work, the water supply system of the humidification system, water supply system whether there is a certain amount of water, the control of boiler water level of the humidifying water level control is normal, whether the normal water level within the humidification boiler. Such as the above, all normal, it would have to check the electrical control system, professional service personnel.

Box-type resistance furnace

Box-type resistance furnace Adaptation
Suitable for ceramics, rare earth magnetic materials, wear-resistant materials such as high-temperature continuous firing.
Box-type resistance furnace Features
1, the series resistance furnace shell made of high quality cold-rolled steel plate, the surface coating process, the door side of the open structure, flexible opening and closing.
2, the temperature box enclosed fire, electric alloy wire heating element coiled into a spiral into the walls of the furnace, heat and temperature uniformity, extending the service life.
3, high-temperature tube resistance furnace with high temperature combustion tube, as in silicon carbide heating elements installed in the furnace jacket.
4, high temperature box resistance furnace with silicon carbide heating element directly in the furnace installation, high thermal efficiency.
5, the series resistance furnace insulation materials selection 0.4-0.6 lightweight foam insulation brick and aluminum silicate fiber cotton, so that the heat storage capacity and thermal conductivity decreased, resulting in the heat storage capacity of the furnace, heating time is shortened, low surface temperature, air furnace power losses, the power consumption is greatly reduced.

Ceramic sintering furnace Features at a glance

The high temperature ceramic or refractory bricks, Outside SECC steel, fine powder coating process.
The seal is made of aluminum plates.
Circular way: thermal radiation (three or four sides heated).
Heating method: PID + SSR or PID + SCR;
Heating material for high-temperature heating wire or silicon carbide;
Temperature range; room +20-1200; (Note: The temperature is adjustable)
Temperature controller: PID microcomputer control;
Timer: timer, thermostat function, temperature and time, the time to cut off the heating power;
Safety Protection: over-temperature protection, high temperature protection, over-current protection.
Can pass an inert gas (such as nitrogen);
(Optional configuration: according to customer product requirements installer tables, recorders, test holes, cart, etc.)
The scope of application of the ceramic sintering furnace
Special ceramics, structural ceramics, silicon nitride, electronic ceramics, functional ceramics, zirconia, alumina, magnetic materials, electronic powder, electronic devices such as sintered ceramic metalization.
Ceramic sintering furnace technology indicators
1, using the SR1/3/4 series of instruments, the use of multi-zone temperature control, PID intelligent digital temperature controller, new digital display, intelligent control technology, can be reduced depending on the read and the human operator error, greatly improve work efficiency, double figures key setting, over-temperature alarm. Microcomputer automatic control, each section of the power limit, Phase voltage thyristor controlled heating. No duty.
2, heating up fast, environmentally friendly energy, high precision, stable performance, good insulation effect.
3, furnace a clean refractory brick mold made, good insulation properties, thermal shock resistance, high temperature resistance, resistance to thermal shock.
4, compared with intermittent furnace operation with high efficiency, easy operation, good temperature stability, and high rate of qualified products.

The structure of the oven drying oven is divided into

Ordinary and blast. The blast oven equipped with a fan in the box, to expedite the convection of hot air to keep the temperature uniform. So the items inside the evaporation of water vapor the accelerated dissipation to the air outside the box, in order to improve the drying efficiency.
The oven is divided into: ordinary and blast. The blast oven equipped with a fan in the box, to expedite the convection of hot air to keep the temperature uniform. So the items inside the evaporation of water vapor the accelerated dissipation to the air outside the box, in order to improve the drying efficiency.
Oven for dry goods or dry heat sterilization. Thermostat-regulated range (50 to 200) ° C ((50 to 250) ° C (50 to 300) 0C).
First, the structure of the oven
Oven and shouting oven or oven. Mainly composed of three parts by the cabinet, the electric heater and a temperature control system.
The cabinet enclosure, thermostatic chamber door, vent, side room.
Enclosure Material: housing made of thin iron (or steel sheet). Box wall is divided into three (including housing), formed between the three iron inside and outside the two mezzanine, outside the sandwich filled with insulation materials (glass fiber or asbestos), within the sandwich as a hot air convection layer.
A thermostatic chamber: the space surrounded by the innermost layer of the iron plate is called a thermostatic chamber. Within 2 to 3 layers of mesh shelves for placing items. Extends into the heated indoor temperature controller temperature probe (temperature sensing part) from the left side wall. Equipped with a heating wire in the bottom of the sandwich.
Door: usually are double. Glass door and the inner door is used to reduce heat loss in the case of observation of the baked article. Exterior doors for insulation.
Inlet and exhaust vent: the bottom or side of an air intake, Click here to go to the dry air. The top of the box with a row of holes, are equipped with adjustable exhaust window in it at the outlet, thereby escaping steam. The exhaust windows central insert a thermometer to indicate the temperature inside the box.
Side room: control room. Generally located in the left side of the box, with the thermostatic chamber thermal insulation separated. The installation of switches, lights, temperature controllers, blowers and other electrical components. Open side chamber door can easily repair the circuit outside the electric wire.
Some electric box control room in the box below.
Second, the electric heater
    The oven heater usually consists of four electric wire parallel. Uniform heating wire coiled in firing by the refractory insulation board. Usually divided into two groups, control changeover switch. The total power (2 to 4) up to 8 kW kW power. The higher the power, the larger the box.
Third, the temperature control system
    Before oven temperature control system, there is usually a differential rod and two mercury thermometer. Used on modern production oven temperature control system is mainly provided by the temperature sensor, the temperature control circuit, relay, temperature setting and a temperature display part.



Powder metallurgy protective atmosphere sintering furnace

Powder metallurgy protective atmosphere sintering furnace introduced
Powder metallurgy protective atmosphere sintering furnace for the production of molding powder metallurgy products, sintering process and the special equipment for continuous operation under controlled atmosphere protection. This equipment can be divided into a furnace, belt drive, Appliance control of three parts, the working characteristics of the workpiece by the mesh belt from the feed port into the sintering zone, in each thermostat region sintering, and then cooled, the material will complete the entire process.
Powder metallurgy protective atmosphere sintering furnace body structure
Powder metallurgy sintering furnace protective atmosphere furnace into the feed intake, the sintering zone, the discharge of water cooling jacket, the furnace shell and skeleton welded steel plate and steel furnace and the furnace shell with good insulation properties of silicon acid aluminum fiber insulation layer, ultra-lightweight anti-carburizing the firebrick refractory layer, with good strength and fire resistance. Placed in the furnace high temperature, corrosion-resistant corundum pallets, high strength, not easy to deformation. The heating elements Cr20Ni80 material, are installed in the lower part of the corundum pallets wear will be easy to replace the resistance wire, sliding roller and adjusting screw mounted in the discharge water cooling jacket, the height can be adjusted from the impact of any force , to prolong the service life of the equipment package.
Powder metallurgy protective atmosphere sintering furnace mesh belt structure
Processes of powder metallurgy sintering furnace protective atmosphere with all the network transmission, using imported 310S high temperature stainless steel wire mesh belt around the system, feed port is equipped with mesh belt transmission mechanism, the workpiece through the feed inlet, sintering zone, the cooling water jacket, the discharge port, mesh belt driven wheel around the spout to return to the feed inlet, the lower part of the furnace, mesh belt speed two-stage pendulum pin reducer reducer FM motor running speed can be arbitrarily changed.
Powder metallurgy protective atmosphere sintering furnace control system
Powder metallurgy sintering furnace protective atmosphere electrical control system is controlled by SCR PID automatic temperature control, power and temperature of each temperature zone can be individually controlled and adjust to meet the iron-based sintered process technology requirements, and with overcurrent protection, Fast Acting, overvoltage protection, the RC circuit. Temperature controller with intelligent digital instrument, temperature control accuracy of ± 1 ℃, with over-temperature alarm system.

Experimental muffle furnace

Experimental muffle furnace:
Experimental muffle furnace is based on the analysis of coal by the China Institute of Science and Technology of the Ministry of Coal "GB212-91 standard specifies requirements and design, for easy maintenance of the furnace, stoves can be withdrawn from the furnace, compared with similar furnace maintenance is extremely convenient. Furnace equipped with controllable chimney, especially suitable for the analysis of the coal samples for chemical analysis and chemical raw materials and products. Metal shell, smooth and beautiful appearance, durable.
Experimental use of muffle furnace:
Experimental muffle furnace for the general equipment of the laboratory for the determination of coal moisture, dry items, drying and other heating purposes. Available coal, chemicals, building materials, electric power, metallurgy, geological exploration and scientific research units laboratory for sintering, heating and heat treatment.
Experiment muffle furnace features:
1, the experimental muffle furnace with silicon carbide heating elements.
2, laboratory muffle furnace heating up fast, good insulation properties, load loss, temperature uniformity.
3, laboratory muffle furnace lining high alumina furnace, furnace shell electrostatic spraying.
4, the temperature control system in two ways, which KSY Series controller using intelligent temperature controller-specific modules, with high control precision, over-temperature protection, KSW series controller bit temperature control with accurate temperature control, easy to operate.

IGBT medium frequency induction melting furnace Products and Features

Products:
This is a new type of IGBT frequency induction melting furnace. It is mainly used for smelting ordinary carbon steel, alloy steel, cast steel, cast iron, non-ferrous metals copper, aluminum, alloy. With high efficiency, melting fast, easy operation. This new power supply with a series resonant output voltage type inverse variable. Inverter part of the state-of-the-art IGBT transistor. The performance of this new type of power supply in many ways better than the thyristor frequency power supply.
Main features:
1 power than tube-type power 30% the SCR frequency than 20%.
(2) stable performance, complete protection, no worries.
(3) heating speed no oxide layer, small deformation.
IGBT IF melting furnace volume and light weight, easy to install.
5. Sensor from the transformer isolation, security.
6. Environmental noise pollution and dust.
Adaptable heating a wide variety of parts.
Temperature and heating time can be precisely controlled. Processing of high quality.
